Paneltronics, Circuit Breaker, Single Pole, A Frame, 20 Amp

$14.12
Paneltronics, Circuit Breaker, Single Pole, A Frame, 20 Amp
SKU: 563153
|
Mfg# 206-073S
|
UNIT: Each
Description: Single Pole A Frame Circuit BreakerBreaker Capacity: 10 Amp
Contact us for availability

Paneltronics, 0 amp Circuit Breaker 206-073S is a single pole, A frame, standard branch AC or DC circuit breaker for marine breaker panels. This panel meets all American Boat and Yacht Council (ABYC) Standards is UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada (ABYC E-11.12.2.8.).

  • Minimum Paneltronics order of 3 breakers or $40
  • Standard branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breaker
  • UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada (ABYC E-11.12.2.8.)
  • Trip free (ABYC E-11.12.1.7.2.2. and E-11.12.2.8.1.)
  • Manual reset (ABYC E-11.12.1.7.2.4. and E-11.12.2.8.1.)

Specifications:
  • Handle Color: White
  • Maximum Voltage / AIC Rating: 32VDC / 2,500 Amps with no Back-up Fuse (ABYC E-11.12.1.7.2.3.), 250VAC 50/60HZ / 3,650 Amps with maximum rated series 80 Amp Back-up Fuse (ABYC E-11.12.2.8.2.)
  • Rated Switch Cycles: 10,000 actuations at rated current and voltage
  • Electrical Hardware: Screw, 10-32 X 3/8" pan combo head (P/N 197-015)
  • Mounting Hardware: Screw, 6-32 X 5/16" black flat Phillips head (P/N 197-002), Screw, 6-32 X 5/16" white flat Phillips head (P/N 197-002W), Hole Plugs 5/8" diameter, Black (P/N 016-005), and White (P/N 016-017)

Ratings & Reviews

No reviews available

Be the first to Write a Review

Warranty:

  • Paneltronics Inc. warrants its products to be free from defects in materials and workmanship under normal use for a period of Three 3 years from the date of purchase. In the event a defect in any part or parts appears within the warranty period, the product must be returned to Paneltronics, Inc. for replacement, repair, or refund.

    Return:

  • All products are non-returnable unless defective.
  • Manufacturer defects reported within 30 days of receipt will be supplied a pre-paid label for return shipping upon approval.
  • Please contact Go2marine LFS Marine and Outdoor for Manufacture Defects, Returns and help with Warranties.
