Newport Ports - 8RD Round Drain Ports, 8"

Mfr: Beckson Marine
$153.58 to $167.55
$153.58 to $167.55
    The overall dimension is the trim ring or frame size. Please make sure to measure the length of the thru-hull portion with the lens closed to the edge of the trim ring. That will tell you how long a spigot you need. The spigot should be flush with the edge of the trim ring. This will maximize the draining action of the frame.
  • Ideal for mounting where installation is within 15° of vertical (with spigot length up to 1" – longer spigots are available for vertical installations)
  • Designed with angled drainage ramp molded into straight spigot to promote drainage and allow for thru-bolting
  • Design promotes drainage without having to make angled cuts in hull
  • Internal angle seats tightly against gasket and lens, omitting exterior water retention ledge present in most other ports
  • Watertight, UV-resistant, corrosion-free frame
  • Supplied with Beckson patented cam latches, insect screen and exterior trim ring
Item #
MPN
Description
Color
Lens Color
Lens OD
Screen OD
Outside Frame Dimension
Spigot Hole Cut Size
Newport Self Drain Port - 8RD Black w/ Clear Lens, 8"
Item #:543437-BLK-CLRLNS
MPN:PO8RD-BC-20
Description: Self Drain
Color: Black
Lens Color: Clear
Lens OD: 8-1/2"
Screen OD: 8"
Outside Frame Dimension: 10-3/4"
Spigot Hole Cut Size: 8-1/2"
Newport Self Drain Port - 8RD White w/ Clear Lens, 8"
Item #:543437-WHT-CLRLNS
MPN:PO8RD-WC-20
Description: Self Drain
Color: White
Lens Color: Clear
Lens OD: 8-1/2"
Screen OD: 8"
Outside Frame Dimension: 10-3/4"
Spigot Hole Cut Size: 8-1/2"
Newport Self Drain Port - 8RD Black w/ Smoked Lens, 8"
Item #:543437-BLK-SMKLNS
MPN:PO8RD-BS-20
Description: Self Drain
Color: Black
Lens Color: Smoked
Lens OD: 8-1/2"
Screen OD: 8"
Outside Frame Dimension: 10-3/4"
Spigot Hole Cut Size: 8-1/2"
