12V Electronic Fast Fall System for Hero and Patriot Units, EZ-0404


12V Electronic Fast Fall System for Hero and Patriot Units, EZ-0404
SKU: 563077
Mfg# EZ-0404
LFS# EZ0404
UNIT: Each
Out of stock - Typically Available in 3 - 6 Weeks



We are proud to have our electronic Fast Fall system for boat winches, with a world winning design. It is mechanical clutch free, which increases the speed of the motor on the way down, comparably as fast as you can freely drop your anchor. Other winch brands go up just as fast as they go down, this draws more current which could lead to overloads, battery drainage, and winch failure. Regardless the E-Z Anchor Puller Fast Fall system drops the anchor significantly faster than all other fixed speed boat winches. Our EFF Electronic Fast Fall System can also be retro-fitted to almost any E-Z Anchor Puller! Our EFF units are simply wired between the battery and the winch and works with all of our HERO and PATRIOT drum winches. If you have a larger model, please contact us for alternate options. Doubles your anchor drop speed, Clutch free, no moving parts!, Can be retrofitted at any time, International Award Winning Design.

What's Included

Compatible with Hero and Patriot Direct Drive Units!

12volt system

Instruction & Wiring Manual

Wiring Terminals for Solenoid and Optional Wireless Remote


Compatible with Hero and Patriot Direct Drive Units!

Clutch-free; No moving parts!

Can be turned on and off according to your in-the-moment needs

Vessel Length 18' - 55' / 6m - 16.8m

Avg. Deployment Speed 200 ft. per minute w/ any direct drive unit

Power Supply via Drum Anchor Winch(Dc) 12v

Net Weight 10 lb / 4.5 kg

Electronic Fast Fall System Manual

Web Brochure
