Life Jacket Re-Arm Kit Cross-Reference by Leland Gas
Bluestorm / Cabela's
| Model |
Type |
Rearm Kit |
Part # |
| SP3F (94-3065) |
Manual |
24g w/Halkey Bayonet |
V86160-84204Z |
| Guardian P3F (94-3057) |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| SP6F (94-3056) |
Auto |
24g w/Halkey yellow bobbin & green clip |
V90000-84204Z
|
| P1F (94-3059) |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z
|
| P6F (94-3058) |
Auto |
33g w/Halkey yellow bobbin & green clip |
V90000-85202Z
|
Body Glove
| Model |
Type |
Rearm Kit |
Part # |
| I-007M |
Manual |
25g w/Halkey green pin |
840AMU-84121Z
|
| I-008M |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| I-007A |
Auto |
24g w/Halkey yellow bobbin & green clip |
V90000-84204Z
|
| I-008A |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z
|
Coleman / Stearns / SOSpenders - MANUAL
| Model |
Type |
Rearm Kit |
Part # |
| 12MCH / 12MYH |
Manual |
12g w/Halkey green pin |
840AMU-81123Z |
| 16MBD / 16MBP / 0340 / 4430 / 6340 |
Manual |
16g w/Halkey green pin |
840AMU-82123Z |
| 1125 |
Manual |
23g w/Halkey green pin |
840AMU-84203
|
| 24MSPT--2 / 24M11-B23 / 24M11-S22 |
Manual |
24g with Halkey green pin |
840AMU-84204Z
|
| 24MSPT / 24MSP-1 |
Manual |
24g w/Halkey Bayonet |
V86160-84204Z
|
| 25MSPT-1 / 0364 / 0367 / 1131 / 1133 / 4444 / I444 |
Manual |
25g w/Halkey green pin |
840AMU-84121Z
|
| 1139 / 0375 / I375 / 1138 / 1143 |
Manual |
33g w/Halkey green pin |
840AMU-85202Z |
| 33MSPT |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z |
| 38MSTD-1 / 38MPRO-1 / 38MHAR-P-1 / 38MWB-1 / 38MHAR-1 |
Manual |
38g w/Halkey green pin |
840AMU-86121Z |
| 38 B (SOLAS) / 38 C (SOLAS) / 38SB / 38SC |
Manual |
38g w/Halkey green pin |
840AMU-86121Z |
| 38LMNG / 38MHRN / 38MREG / 38MBP |
Manual |
38g w/Halkey Bayonet |
V86160-86202Z |
| 1189 / 1193 / 33M42-V17 / 33M42-B06 / 33M42-B06-D |
Manual |
33g w/Secumar Bayonet |
401SEC-85203Z |
Coleman / Stearns / SOSpenders - AUTOMATIC
| Model |
Type |
Rearm Kit |
Part # |
| 12ACH / 12ACH-II / 12AYH / 12AYH-II |
Auto |
12g w/Halkey yellow bobbin & green pin |
V85000-81123Z |
| 24ASPT |
Auto |
24g w/Halkey yellow bobbin & green pin |
V85000-84204Z |
| 24ASPT-1 / 24A13-S21 |
Auto |
24g w/Halkey yellow bobbin & green clip |
V90000-84204Z
|
| 25ASPT / 1330 / 1331 |
Auto |
25g w/Halkey yellow bobbin & green pin |
V85000-84121Z |
| 1469 / 1470 / 1473 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z |
| 1439 / 1443 |
Auto |
33g w/Secumar Bayonet & pill |
4001SEC-85203Z |
| 38ASTD / 38APRO / 38AHAR / 38AHAR-P / 38AMPV |
Auto |
38g w/Halkey yellow bobbin & green pin |
V85000-86121Z
|
| 38B (SOLAS) / 38C (SOLAS) / 38SB / 38SC |
Auto |
38g w/Halkey yellow bobbin & green pin |
V85000-86121Z
|
| 38ALNG / 38AHRN / 38AREG |
Auto |
38g w/Halkey yellow bobbin & green pin |
V85000-86202Z |
| 38AS STD / 38AS HAR / 38AS PRO / 38CHR |
Auto |
38g w/Halkey Bayonet & yellow bobbin |
V85000-86202Z |
Eastern Aero Marine
| Model |
Type |
Rearm Kit |
Part # |
| P01080-101 / P01080-201 |
Manual |
33g w/Halkey green pin |
V85000-86202Z |
| P01080-301 / P01080-401 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z |
| P01080-103 / P01080-203 |
Auto |
33g w/Halkey yellow bobbin & green pin |
V85000-85202Z |
| P01080-303 / P01080-403 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z |
Float-Tech
| Model |
Type |
Rearm Kit |
Part # |
| FT-HRA-R5-1 / 2 / 3 / 4 / 5 / 6 / 7 |
Auto |
24g w/Halkey yellow bobbin & green clip |
V90000-84204Z |
Helly Hansen (Climate Technical Gear)
| Model |
Type |
Rearm Kit |
Part # |
| M6F / NIV500 |
Manual |
33g w/Halkey green pin |
840AMU-85202Z |
| HI100 / HI150 / HI1000 / HI1500 / HI300 / HI350 / HI3000 / HI3500 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| NIV300 / NIV350 / NI700 / NIV1000 / NIV1500 / NIV3000 / NIV3500 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| HI200 / HI250 / HI400 / NI400 / HI450 / NIV450 / NI800 / HI2000 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z
|
| NIV2000 / NIV2500 / HI2500 / HI4000 / NIV4000 / HI4500 / NIV4500 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z |
| A6F / NIV600 |
Auto |
33g w/Halkey yellow bobbin & green clip |
V90000-85202Z |
International Safety Products
| Model |
Type |
Rearm Kit |
Part # |
| 085USC15M |
Manual |
33g w/Halkey green pin |
840AMU-85202Z |
| 085USC15A |
Auto |
33g w/Halkey yellow bobbin & green pin |
V85000-85202Z |
Mustang Survival
| Model |
Type |
Rearm Kit |
Part # |
| MD2010 |
Manual |
20g w/Halkey green pin |
840AMU-84201 |
| MD1166 / MD3000 / MD3003 / MD3004 / MD3010 / MD3015 / MD3020 / MD3021 / MD3025 / MD3025-NV / MD3091 |
Manual |
33g w/Halkey green pin |
840AMU-85202Z |
| MD2051 / MD2085 / MD3051 / MD3052 / MD3071 / MD3075 / MD3081 / MD3082 / MD3085 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z |
| MD0100 |
Manual |
38g w/Halkey Bayonet |
V86160-85202Z |
| MD2012 |
Auto |
20g w/Halkey yellow bobbin & green pin |
V85000-84201 |
| MD3001 / MD3002 / MD3017 / MD3019 / MD3031 / MD3032 |
Auto |
33g w/Halkey yellow bobbin & green pin |
V85000-85202Z |
| MD2053 / MD2087 / MD3053 / MD3054 / MD3083 / MD3084 / MD3087 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z |
| MD0200 / MC1900 / MC1900 HR |
Auto |
38g w/Halkey Bayonet & yellow bobbin |
V86000-86202Z |
| MD2014 / MD2015 |
Auto |
38g w/Halkey yellow bobbin & green pin |
V86160-84204Z
|
| MD2016 |
Auto |
38g w/Halkey yellow bobbin & green pin |
V86000-84204Z
|
| MD3183 |
Auto |
33g Hammar Inflator |
MA-7214 |
O'Rizon
| Model |
Type |
Rearm Kit |
Part # |
| OR-INF-M |
Manual |
33g w/Halkey green pin |
840AMU-85202Z |
| OR-INF-A |
Auto |
33g w/Halkey yellow bobbin & green pin |
V85000-85202Z |
Revere
| Model |
Type |
Rearm Kit |
Part # |
| 61018 / 61020 / 61098 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z |
| 61245 |
Auto |
24g w/Halkey Bayonet & yellow bobbin |
V86000-84204Z |
| 61019 / 61021 / 61225 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z |
Sagittarius
| Model |
Type |
Rearm Kit |
Part # |
| 61245 |
Auto |
24g w/Halkey Bayonet & yellow bobbin |
V86000-84204Z
|
Takashina
| Model |
Type |
Rearm Kit |
Part # |
| SP3F / BP3F (24) |
Manual |
24g w/Halkey Bayonet |
V86160-84204Z |
| SP6FM |
Manual |
24g w/Halkey green pin |
840AMU-84204Z
|
| PV3F / BP3F (33) / SH3F / TH3F / TD3F / T3F / P3F / S3F |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| SP1F |
Auto |
24g w/Halkey Bayonet & yellow bobbin |
V86000-84204Z |
| PV1F / SH1F / TH1F / TD1F / T1F / P1F / S1F |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z
|
| SP6F / SP6FA |
Auto |
24g w/Halkey yellow bobbin & green clip |
V90000-84204Z
|
| P6F / S6F |
Auto |
33g w/Halkey yellow bobbin & green clip |
V90000-85202Z |
| SL1H |
Auto/Manual |
24g, 1/2"-20 THD Cylinder with Halkey bobbin |
V95000-84204Z |
| T1H, TD1H, TH1H |
Auto/Manual |
33g, 1/2"-20 THD Cylinder with Halkey bobbin |
V95000-85202Z |
D1H, DD1H, DH1H
Z1H, ZD1H, ZH1H |
Auto/Manual |
38g, 1/2"-20 THD Cylinder with Halkey bobbin |
V95000-86202Z |
West Marine
| Model |
Type |
Rearm Kit |
Part # |
| 10997435 |
Manual |
24g w/Halkey Bayonet |
V86160-84204Z |
| 10997492 |
Manual |
33g w/Halkey Bayonet |
V86160-85202Z
|
| 10997443 / 10997450 / 10997468 |
Auto |
24g w/Halkey Bayonet & yellow bobbin |
V86000-84204Z
|
| 10127660 |
Auto |
24g w/Halkey yellow bobbin green clip |
V90000-84204Z
|
| 10997476 / 10997484 |
Auto |
33g w/Halkey Bayonet & yellow bobbin |
V86000-85202Z
|
