Description
Protects Electrical Circuits allows from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction..
High Interrupt Current to safely protects circuits connected to large paralleled battery banks with significant available power AC & DC Rated to cover a wide range of system application needs.
Stainless Steel Self Locking Hardware ensures robust connections & long term connection reliability.
Easily Mounts In Standard Panels accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws .
4 Year Warranty: We stand behind our product's ability to meet your needs. CONTINUOUS
CURRENT (AMPS)
15
MAX VOLTAGE
277 Vac / 80 Vdc
regulatory compliance
UL 1077
Electrical Endurance @ Rated current
6,000 Cycles?
Interrupt Capacity
5kA / 277Vac, 1.5kA / 80 Vdc
CE Marked?
Yes
