Description
Technical Specifications
- Product Type: Hydraulic Spin-on
- Notes: Can be used with OB1313, OB1314, OB1315 and OB1316 bases.
- Thread Size: 1 1/4-11 BSP-PL
- Outside Diameter: 5 (127.0)
- Length: 7 3/32 (180.2)
- Includes: I. Gasket: [1] Included
- Related To: BT8450 (with Anti-Drainback Valve, 15 PSID By-Pass Valve)
- Micron Rating: 9.8 Nominal; 27 Absolute
- Compatible Competitor Part Number: J.C. Bamford 32/901401
- Application: Aveling-Barford, Braud, J.C. Bamford, Liebherr, New Holland Equipment
- Brand: Baldwin
- Industry: Marine
Mining
Oil and gas
Construction
Agriculture
Compressor - Product Style: Hydraulic Filter
- Technology: Filtration
- No CAD files available
Item Information
Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic filters. Baldwin hydraulic filters utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications
