Description
- Vibrations, shock, thermoshock, moisture and salt spray resistant
- Mounts in Blue Sea Systems Contura Water Resistant Panels and Contura Switch Mounting Panels
| Specifications | |
|---|---|
| Action | (ON)-OFF-ON |
| Pole / Throw | SPDT |
| Actuator Color | Black - Contura III |
| Common Applications | bilge pumps |
| Maximum Amperage | 20A @ 12V DC 15A @ 24V DC |
| Amperage Operating Current | 18mA (LED) |
| Minimum Operating Temperature | -40° C |
| Maximum Operating Temperature | 85° C |
| Actuator Position to Light LED | (ON) |
| Embedded LEDs | 1 |
| Lighting | LED rated 100,000 hours half-life |
| Seals | Internal and external gasket panel seal |
| Weight | 0.08lb (0.04 kg) |
