Description
SPX FLOW engineers Johnson Pump impellers for outstanding performance!
SPX FLOW supplies engine cooling pumps to the world’s leading marine motor manufacturers, not just because of our renowned pumps; but also because of the heart of an engine cooling pump: the impeller!
With SPX FLOW Johnson Pump Marine Original Impellers you get:
- Ensures correct cooling flow
- Stable pressure delivery over time
- Significantly longer service life
- Excellent self-priming capability
- Ensures sufficient cooling directly at start up
- Our impellers are manufactured to strict tolerances for optimal functionality unique MC97 rubber compound in many of our impellers
- Correct impeller dimensions
- Optimized to provide maximum life, especially for applications where the end user doesn’t run the engine on a regular basis:
- Stable pressure delivery over time
- Minimized failures due to fatigue
- Minimized swelling
DEVELOPMENTAL KNOW-HOW
With its Johnson Pump brand SPX FLOW is an original manufacturer of world
class impellers for more than 50 years
- More than 125 years of accumulated engineering time.
- Documented, standardized testing
- Continuous quality testing, annually 150,000 test hours
- In excess of 150,000 hours testing of our MC97 rubber compound
| Ref. | Pump | Impeller Kit | Material * | Outer dia | Inner dia | Width | Replaces Jabsco No | ||||
| mm | inch | mm | inch | mm | inch | Europe | USA | ||||
| 1 | F2 | 09-1077B-9 | Nitrile | 35.2 | 1.29 | 8.0 / Flat | 0.31 / Flat | 12.7 | 0.50 | ||
| 2 | F3 | 09-843S-9 | Nitrile | 45.2 | 1.78 | 8.0 / Flat | 0.31 / Flat | 12.8 | 0.50 | ||
| 3 | TA3P10 | 09-1052S-9 | Nitrile | 45.2 | 1.78 | 8.0 / Flat | 0.31 / Flat | 12.8 | 0.50 | ||
| 4 | F35 | 09-806B-1 | MC97/EPDM | 40.0 | 1.58 | 9.5 | 0.37 | 19.0 | 0.75 | 4528-0001 | |
| 5 | F35 | 09-808B-1 | MC97/EPDM | 40.0 | 1.58 | 12.0 | 0.47 | 19.0 | 0.75 | 22405-0001 | |
| 6 | F4 | 09-824P-1 | MC97/EPDM | 50.8 | 2.00 | 8.0 / Flat | 0.31 / Flat | 22.0 | 0.87 | ||
| 6 | F4 | 09-824P-9 | Nitrile | 50.8 | 2.00 | 8.0 / Flat | 0.31 / Flat | 22.0 | 0.87 | 6303-0003 | |
| 6.2 | F4 | 09-824P-2 | Polyeurethane | 50.8 | 2.00 | 8.0 / Flat | 0.31 / Flat | 22.0 | 0.87 | 6303-007-P “Green Impeller” | |
| * MC97/EPDM and Neoprene - for cooling, Nitrile - oil resistant | |||||||||||
