Description
• Compact inline 4 position fuse block has single side wire entry for tight installation spaces.
• Protects Branch Circuits by accepting ATO style fuses ranging from 1 through 40 Amps.
Harsh Environment Design with stainless steel self-locking hardware
Bullet-proof Construction: Designed with high temperature materials and stainless steel self-locking hardware allow mounting anywhere on vehicle.
Supports SAE Circuit Protection Standards for thermal/short circuit events.
Includes Latching Protective Cover with integrated label recesses for easy circuit/fuse identification
CONTINUOUS CURRENT Per Circuit (AMPS) : 30
MAXIMUM CURRENT (ENTIRE BLOCK) AMPS : 100
NOMINAL VOLTAGE : 12/24Vdc
MAX VOLTAGE (VDC) : 60
HARDWARE MATERIAL: Stainless Steel
INPUT TERMINAL SIZE: M5-0.8
Additional Information
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit P65Warnings.ca.gov
