Description
Specifications
- People safe at design concentration
- Environmentally responsible (no ozone depletion and GWP (global warming potential) of less than 1)
- Globally accepted
- Not damaging to equipment & machinery
- No clean-up after discharge
- No foreseeable phase-out schedule
Applications Include
- Engine Compartment
- Machinery Compartment
- Generator Area
- Electrical Control Room
- Fuel Storage Lockers
- Lazarette
System Specifications
- Protects spaces up to 1800 ft³ (51m³)
- Activation Temp: NFD 101-1800 | 175-225°F (79-107°C)
- NFD models are refillable (FK-5-1-12 Agent)
- Operating Temperature Range 20-130°F (-7-55°C)
- The automatic/manual fire extinguishers require a SMAC Auto/Manual Cable
- Installation Manual
- NOVEC PRE-ENGINEERED CE CERTIFICATE
- Data Sheet NFG 25-500-001
Features
- Pre-engineered to protect a specific volume of enclosed space
- Automatically discharged through heat activation
- System supervisory pressure switch
- Comes with safety pin to arm/disarm manual cable release during inspection/maintenance
- Equipped with bi-directional cable release bracket for ease of install from either side of cylinder
- Made in the U.S.A.
