Description
Suitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46)
| Specifications | |
|---|---|
| Actuator Style | Flat Rocker |
| Poles | 1 |
| Maximum Voltage | 80V DC |
| Circuit Breaker Type | Magnetic Hydraulic—Trip free |
| Interrupt Capacity | 10000A |
| Minimum Operating Temperature | -40° C |
| Maximum Operating Temperature | 85° C |
| Mounting Screw | #6-32 SS |
| Mounting Screw Torque | 7-9 in-lb (0.79 Nm) |
